Vertical Slimline Tanks
Our Vertical Slimline Tanks are available in two options for both water and diesel, 55L Wellbody Tanks and 65L Canopy Tanks.
55L Wellbody Tanks fit most dual cab utes below the tonneau cover. 65L Canopy Tanks may be used for drop-side utes, open tray-backs or with canopy.
- Option of UV-stabilised food grade polyethylene or UV-stabilised diesel grade polyethylene
- Brackets available or strap-in option
- Gravity feed or pump option
- Hose kits for water or diesel available
Features and Benefits
- Stylish, slimline design
- Option of UV-stabilised food grade polyethylene or UV stabilised diesel grade polyethylene
- Site tube level gauge
- 40mm lockable filler cap
- Brackets available or strap-in option
- Gravity feed or pump option
- Hose Kits for water or diesel available
55L Wellbody Tanks
- Fits most dual cab utes below tonneau cover
- Fits in the gap between cargo drawers and the tub wall on dual cab. Great use of this wasted space.
- Fits wheel arches in dual cab tubs
- 1/2” brass BSP outlet
65L Canopy Tanks
- May be used for drop-side utes, open tray-backs or with canopy
- Uses minimal space under canopy
- 1/2” poly BSP outlet
55L Wellbody Tank Water (Black)
Specifications
Length: 1,295mm
Width: 175mm
Height: 445mm
Site tube level gauge
40mm lockable filler cap
1/2” brass BSP outlet
Does not include hose or brackets
55L Wellbody Tank Water (Non Standard Colour)
Specifications
Length: 1,295mm
Width: 175mm
Height: 445mm
Site tube level gauge
40mm lockable filler cap
1/2” brass BSP outlet
Does not include hose or brackets
55L Wellbody Tank Water with Diaphragm Pump
Specifications
Length: 1,295mm
Width: 175mm
Height: 445mm
Site tube level gauge
40mm lockable filler cap
1/2” brass BSP outlet
Does not include hose or brackets
55L Wellbody Tank Water with Submersible Pump
Specifications
Length: 1,295mm
Width: 175mm
Height: 445mm
Site tube level gauge
40mm lockable filler cap
1/2” brass BSP outlet
Does not include hose or brackets
55L Wellbody Tank Diesel (Grey)
Specifications
Length: 1,295mm
Width: 175mm
Height: 445mm
Site tube level gauge
40mm lockable filler cap
1/2” brass BSP outlet
Does not include hose or brackets
55L Wellbody Tank Diesel with Submersible Pump
Specifications
Length: 1,295mm
Width: 175mm
Height: 445mm
Site tube level gauge
40mm lockable filler cap
1/2” brass BSP outlet
Does not include hose or brackets
65L Canopy Tank Water (Black)
Specifications
Length: 1,590mm
Width: 120mm
Height: 590mm
Site tube level gauge
40mm lockable filler cap
1/2” poly BSP outlet
Does not include hose or brackets
65L Canopy Tank Water (Non Standard Colour)
Specifications
Length: 1,590mm
Width: 120mm
Height: 590mm
Site tube level gauge
40mm lockable filler cap
1/2” poly BSP outlet
Does not include hose or brackets
65L Canopy Tank Water with Diaphragm Pump
Specifications
Length: 1,590mm
Width: 120mm
Height: 590mm
Site tube level gauge
40mm lockable filler cap
1/2” poly BSP outlet
Does not include hose or brackets
65L Canopy Tank Water with Submersible Pump
Specifications
Length: 1,590mm
Width: 120mm
Height: 590mm
Site tube level gauge
40mm lockable filler cap
1/2” poly BSP outlet
Does not include hose or brackets
65L Canopy Tank Diesel (Grey)
Specifications
Length: 1,590mm
Width: 120mm
Height: 590mm
Site tube level gauge
40mm lockable filler cap
1/2” poly BSP outlet
Does not include hose or brackets
65L Canopy Tank Diesel with Submersible Pump
Specifications
Length: 1,590mm
Width: 120mm
Height: 590mm
Site tube level gauge
40mm lockable filler cap
1/2” poly BSP outlet
Does not include hose or brackets
